GitHub Actions vs GitLab Pipeline

It's been almost 5 years since my last post. Time for a new one 😅

Developers¹ spend a lot of time with source control systems like GitHub and GitLab. I would rate the choice of these systems as one of the most important decisions a development team can make. I have often seen choices made on simplistic criteria — that it's open source and free to host. I want to take a more holistic view and reason about the overall system design.

In this first post, I want to focus only on the CI/CD pipelines from GitHub and GitLab and the tradeoffs of each. A second post will cover other features — issue tracking for communication, the ability to build custom solutions on top of the APIs, granular permissions on those APIs, and securely integrating with other systems (CI talking to a cloud provider over OIDC). ...hopefully soon 😁

YAML is your CI/CD design

YAML matters in GitHub Actions and GitLab pipelines because it is the surface through which the system exposes itself. It is declarative — we say what we want, not how — which means the vocabulary the platform gives us (events, permissions, jobs, images, stages) is the design. Reading a pipeline YAML carefully tells us what its authors thought was primary, what they made cheap, and what they made hard.

GitHub Actions

Let us look at a simple workflow yaml for GitHub Actions.

on:
  push:
    paths:
      - 'terraform/*.tf'
    branches:
      - main

permissions:
  contents: read
  id-token: write
  pull-requests: write

jobs:
  terraform:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v6
      - uses: hashicorp/setup-terraform@v4
        with:
          terraform_version: '1.14.6'
      - uses: 'google-github-actions/auth@v3'
        with:
          project_id: 'my-project'
          workload_identity_provider: 'projects/123456789/locations/global/workloadIdentityPools/my-pool/providers/my-provider'
      - name: Terraform Init
        working-directory: ./infra
        run: terraform init

Let's take this yaml apart and reason about the design choices.

The on section is a declarative way to specify the events that will trigger this workflow. It also lets us filter those events declaratively — run these steps only if terraform files have changed on the main branch. The fact that on is a keyword in the yaml syntax also means events are first class citizens in GitHub. Making events first class allows the information to be accessed as structured context and we can write code like — if: contains(github.event.comment.body, '/needs-repro')

permissions block declaratively specifies what the workflow can do. It decouples authorization from the jobs that will run. For example, the job can update the pull request with the output of terraform plan because we asked for write access. The YAML also makes it clear that permissions are scoped to the workflow itself, not to the user or actor who triggered it. A GitHub app with admin rights and a Slack message that fires the workflow both get the same permissions.

jobs and steps sections describe the work. Jobs run in parallel on runners; steps execute in sequence inside a job. What is worth noting is what steps share — a workspace filesystem, and that is it. No shared memory, no shared process, no shared runtime. This deliberate weak coupling makes composition safe. Any step can be swapped out and the rest of the job does not need to know.

uses keyword is where composition actually happens, and it tells us something specific about the system. hashicorp/setup-terraform@v4 is not a marketplace entry — it is a reference to a GitHub repository pinned to a git tag. There is no separate registry, no approval process, no publish step. Anyone with a public repo and an action.yaml has extended the system, and anyone else can uses: it.

The flip side of this open composition through uses is that it has been a source of supply-chain attacks. Mutable version tags (force-pushed to point at malicious commits) and untrusted input in workflow scripts are problems that have to be solved every day. It is one of my favorite features but also very hard to justify in a security review 😅

Lastly, everything in the yaml also exists as an API. push is a git event, workflow_dispatch is an api call, permissions is a scope on a short-lived token, artifacts are objects with urls. The yaml is one client of the system, not the system itself. So we can trigger a workflow from a Slack bot, rerun a failed job from a dashboard, gate a deploy from a security scanner, or write our own UI on top. Any tooling we want, we can build.

GitLab Pipeline

Here is roughly the same pipeline in GitLab².

image: hashicorp/terraform:1.14.6

stages:
  - terraform

terraform:
  stage: terraform
  id_tokens:
    GCP_ID_TOKEN:
      aud: 'https://iam.googleapis.com/projects/123456789/locations/global/workloadIdentityPools/my-pool/providers/my-provider'
  rules:
    - if: '$CI_COMMIT_BRANCH == "main"'
      changes:
        - terraform/*.tf
  script:
    - cd infra
    - terraform init

The first thing to notice is that GitLab (the product offering hosted git) is tightly coupled with the pipeline. Nothing in the pipeline yaml is a reference to an event or an api call. Events exist in the system, of course — they are just not available as part of the pipeline yaml.

image as a keyword in yaml is a leaky abstraction. It pulls two separate concerns into the yaml —

• Isolation — we want isolation between steps and between jobs, but how we achieve it should not be baked into the yaml. Runtimes like Deno/WASM or lightweight VMs (Kata Containers, Firecracker) could do the job just as well. Making image a keyword in the YAML definition rules those alternatives out.
• Harder to reason about — exposing the runtime as a container leaks unnecessary detail into the pipeline. What happens if I want to build a docker image as part of CI to test my change? This is one of the most common use cases but tricky to think through once you consider all the failure modes (Docker-in-Docker, privilege escalation, etc).

The decoupling between stages and jobs is a nice design choice. It lets us express more complex workflows and promote between stages with ease. Once we add YAML anchors and workflow inheritance through include and exclude, we can build fairly sophisticated pipelines (better than GitHub Actions).

The API story is different too. GitLab has a good API, but the pipeline is more of a closed object. The yaml, the templates, the images, the registry, and the environments all sit inside GitLab. The pipeline composes well with other GitLab primitives and less well with things outside that boundary. Extensibility here means adopting more of the product, not building whatever we want on top of it.

Expressions

While most pipelines can be built using the constructs we have seen so far — jobs, stages, YAML anchors, and inheritance — much of their power and elegance also comes from expressions.

• GitHub Actions: Expressions are a first-class, relatively powerful mini-language. You access structured contexts (objects) and compose functions. This makes workflows highly dynamic and composable, but the syntax can become nested and hard to read. Everything that can be an expression usually is.

  bash

  # returns true if the issue related to the event has a label "bug".
  contains(github.event.issue.labels.*.name, 'bug')

• GitLab CI: Expressions are simpler and more constrained. The main power for conditionals lives in the rules system (order-evaluated list of conditions) plus specialized keywords (changes, exists). Dynamic configuration has improved with $[[]] (inputs, matrix, components), but runtime expressions remain limited.

  yaml

  rules:
  - if: $CI_COMMIT_BRANCH == "main" && $CI_PIPELINE_SOURCE == "push"
  - if: $CI_COMMIT_MESSAGE =~ /skip-ci/
      when: never

Closing thoughts

The two yamls describe different design philosophies. GitHub's is a thin declarative facade over the functionality the platform offers through its REST APIs. It is more cohesive with the rest of the system and easy to reason about. It is also more extensible because custom tooling is easy to build on top.

GitLab's yaml describes an integrated product where composition, environments, and templates all live inside the pipeline definition itself. It is possible to build cleaner, more sophisticated, DRY pipelines than in GHA. I like to think of GitLab pipelines as the Apple ecosystem — a closed system that is easy to use and hard to extend.

Both solutions solve the problem, even though GitHub and GitLab chose different boundaries for their CI systems. I’d pick GitHub Actions most of the time. It feels more consistent and better designed to me.
